The RME Fireface UFX is a flagship audio interface renowned for its exceptional sound quality, versatility, and extensive connectivity options. With a total of 188 channels, including 12 analog, 16 ADAT, and 64 MADI channels, the Fireface UFX offers unparalleled flexibility for professional recording, mixing, and mastering applications. Its advanced features include ultra-low latency operation, high-resolution converters, and comprehensive TotalMix FX software for flexible routing and monitoring. Equipped with USB 3.0 and Thunderbolt connectivity, the Fireface UFX ensures lightning-fast data transfer and seamless integration with both Mac and PC systems. Experience the pinnacle of audio performance with the RME Fireface UFX .

AD, Line In 1-8, rear

• Resolution AD: 24 bit
• Signal to Noise ratio (SNR): 113 dB RMS unweighted, 116 dBA
• Frequency response @ 44.1 kHz, -0.1 dB: 5 Hz – 20.8 kHz
• Frequency response @ 96 kHz, -0.5 dB: 3 Hz – 45.8 kHz
• Frequency response @ 192 kHz, -1 dB: 2 Hz – 92 kHz
• THD: < -110 dB, < 0.00032 %
• THD N: < -104 dB, < 0.00063 %
• Channel separation: > 110 dB
• Maximum input level: 19 dBu
• Input: 6.3 mm TRS jack, electronically balanced
• Input impedance: 8 kOhm unbalanced, 12 kOhm balanced
• Input sensitivity switchable to Lo Gain, 4 dBu
• Input level for 0 dBFS @ Lo Gain: 19 dBu
• Input level for 0 dBFS @ 4 dBu: 13 dBu
• Variable gain: 0 to 12 dB
• Minimum level for 0 dBFS: 1 dBu, -1.2 dBV

Microphone In 9-12, front

As AD, but:

• Input: XLR, electronically balanced
• Input impedance: 3.4 kOhm
• Signal to Noise ratio (SNR): 115 dB RMS unweighted, 118 dBA
• Gain range: 75 dB
• Maximum input level, Gain 0 dB: 18 dBu
• Maximum input level, Gain 75 dB: -57 dBu
• CLIP LED: 0 dBFS • SIG LED: -60 dBFS

Instrument In 9-12, front

As AD, but:

• Input: 6.3 mm TS jack, unbalanced
• Input impedance: 1 MOhm
• Signal to Noise ratio (SNR): 114 dB RMS unweighted, 118 dBA
• Gain range: 42 dB
• Maximum input level, Gain 8 dB: 21 dBu
• Maximum input level, Gain 50 dB: -21 dBu

DA, Line Out 3-8, rear

• Resolution: 24 bit
• Dynamic range (DR): 115 dB RMS unweighted, 118 dBA
• Frequency response @ 44.1 kHz, -0.5 dB: 5 Hz – 20.8 kHz
• Frequency response @ 96 kHz, -0.5 dB: 5 Hz – 45 kHz
• Frequency response @ 192 kHz, -1 dB: 5 Hz - 89 kHz
• THD: < -110 dB, < 0.00032 %
• THD N: < -104 dB, < 0.00063 %
• Channel separation: > 110 dB
• Maximum output level: 19 dBu
• Output: 6.3 mm TRS jack, servo-balanced
• Output impedance: 75 Ohm unbalanced, 150 Ohm balanced
• Output level switchable Hi Gain, 4 dBu, -10 dBV
• Output level at 0 dBFS @ Hi Gain: 19 dBu
• Output level at 0 dBFS @ 4 dBu: 13 dBu
• Output level at 0 dBFS @ -10 dBV: 2 dBV

DA - Stereo Monitor Output XLR (1-2)

As DA, but:

• Output: XLR, balanced
• Output level switchable 24 dBu, Hi Gain, 4 dBu, -10 dBV
• Output level at 0 dBFS @ 24 dBu: 24 dBu
• Output level at 0 dBFS @ Hi Gain: 19 dBu
• Output level at 0 dBFS @ 4 dBu: 13 dBu
• Output level at 0 dBFS @ -10 dBV: 2 dBV

DA - Stereo Monitor Output Phones (9-12)

As DA, but:

• Output: 2 x 6.3 mm TRS stereo jack, unbalanced
• Maximum output level at 0 dBFS, High: 19 dBu
• Maximum output level at 0 dBFS, Low: 2 dBV
• Output impedance: 2 Ohm
• Max power per channel @ 32 Ohm load, 0.1% THD: 210 mW (2.6 Vrms, 10.5 dBu)

Includes original packaging.

Video:

Product Specs

• Item Number: 31954
• Make:
• Model:
• Condition:
• Finish: Silver
• Categories: ⇒
• Made In: Germany
• MPN: 31954
